CH52-E Outdoor Multisensor Camera
The **Verkada CH52-E** is a four-camera multisensor that features four independent sensors, providing expansive coverage from a single install point with IP66 weather and IK10 impact ratings for interior or exterior deployment.
SKU CH52-1TBE-HW
Total MSRP$6,048
Hardware $4,099 + 3-year cloud license $1,949
Retention
Onboard storage — no NVR or extra recorder required.
Cloud license term
Hardware$4,099
Software · 3-yr cloud license$1,949
Total MSRP$6,048
10-Year Hardware Warranty on this Verkada camera
Authorized Verkada reseller · cloud licensing configured at checkout
Overview
The Verkada CH52-E is a four-camera multisensor that features four independent sensors, providing expansive coverage from a single install point with IP66 weather and IK10 impact ratings for interior or exterior deployment.
- Four 1 / 2.8" progressive CMOS image sensors delivering 20MP (4 x 5MP) of collective resolution
- Four varifocal lenses with 2.08x optical zoom each and 30 meters / 98 feet of IR range for nighttime viewing
- Four onboard CV25S Ambarella processors enabling people and vehicle analytics, AI-powered search, and AI-powered alerts
- Individually adjustable and repositionable sensor heads for a total field of view up to 328°
- 30 - 365 days (1TB - 8TB) of onboard storage with redundant cloud backup and unlimited cloud-based archiving
- Sealed interior components with IP66 weather rating, IK10 impact rating, and operability between -40°C to 50°C / -40°F to 122°F
- Single PoE++ cable required for easy installation
Specifications
- Image Sensor
- 4 x 1 / 2.8" Progressive CMOS
- Sensor Resolution
- 4 x 5MP (2688 x 1944)
- Lens Type
- Varifocal; motorized zoom
- Focal Length
- 3.7 - 7.7mm
- Aperture
- F1.9 - F2.9
- Field of View (after LDC)
- Horizontal: 89° - 37° (82° - 35°); Vertical: 65° - 29° (60° - 26°); Diagonal: 99° - 46° (92° - 43°)
- Sensor Movement
- Tilt: +0°-105° for each lens from horizon; Pan: +/- 90° for each lens; Rotation: +/- 90° for each lens
- IR Range
- 30m / 98ft; non-adjustable
- Minimum Illumination
- 0.009 lux @ F1.9 (color); 0 lux with IR Illuminators on
- WDR Technology
- 120dB dynamic range, true WDR, dual exposure
- Onboard Storage
- Capacity: From 1TB to 8TB; Card: MicroSD, SDXC
- CPU
- 4 x Ambarella CV25S88
- Compression
- H.265, H.264
- Frame Rate
- 24fps / sensor
- Audio
- Not supported
- Power Input
- With IR: IEEE 802.3bt Type 3 PoE++; Without IR: IEEE 802.3at Type 2 PoE+; Extended temperature range: IEEE 802.3bt Type 3 PoE++
- Power Consumption
- With IR: 43-57V, 0.65-0.49A, 27.7W; Without IR: 43-57V, 0.46-0.34A, 19.5W; Extended temperature range: 43-57V, 0.91-0.68A, 38.7W
- Connectivity
- RJ-45 cable connector for network/PoE connection; 10 / 100 Mbps
- Operating Temperature
- -40°C to 50°C / -40°F to 122°F
- Humidity
- 0 to 90%
- Certifications
- FCC, ICES, CE, UKCA, RCM, VCCI, KCC, NOM, CB, NTRA, ICASA, UL/cUL/IEC 62368-1, IK10 impact rating, IP66 weather rating, FY2019 NDAA compliant
- Weight
- Camera: 2900g / 102.29oz; Mount plate: 536g / 18.91oz
- Body
- Aluminum, plastic dome trim
- Dimensions
- Ø: 275.0mm / 10.82in, H: 118.0mm / 4.65in with mount plate; Ø: 267.0mm / 10.51in, H: 114.0mm / 4.49in without mount plate
