Access Control · AC43
AC43 4 Door Controller
The **Verkada AC43** is an easy-to-install, cloud-managed four-door controller that supports up to four doors, two AUX inputs, two AUX outputs, and a fire alarm interface (FAI), providing centralized visibility and control over an Ethernet connection to Command.
SKU AC43-HW-NA
Total MSRP$2,598
Hardware $1,999 + 3-year cloud license $599
Cloud license term
Hardware$1,999
Software · 3-yr cloud license$599
Total MSRP$2,598
Authorized Verkada reseller · cloud licensing configured at checkout
Overview
The Verkada AC43 is an easy-to-install, cloud-managed four-door controller that supports up to four doors, two AUX inputs, two AUX outputs, and a fire alarm interface (FAI), providing centralized visibility and control over an Ethernet connection to Command.
- Supports up to four doors with 2x REX dry inputs and 1x DPI dry input per door, plus 2x auxiliary dry inputs
- Works with Verkada or third-party OSDP and Wiegand readers (1x reader port per door, RS-485 or Wiegand)
- Edge processing with locally cached access configurations keeps doors operating during network outages
- Fire alarm integration (FAI) automatically removes power from maglocks during a fire alarm for faster egress
- Integrated power supply delivers power to door hardware with switch-selectable wet relay options
- Mounts the ACC-CEL-LTE-2 Cellular Backup Communicator directly onto the chassis for LTE backup
- NDAA compliant with a 10-year warranty
Specifications
- Doors supported
- Up to four doors
- Inputs
- 2x REX dry inputs per door; 1x DPI dry input per door; 2x auxiliary dry inputs
- Readers
- 1x reader port (Verkada/RS-485 or Wiegand) per door. Reader current consumption must be < 600 mA per reader power port
- Contact sensors
- 4 contact sensors. Nominal 5VDC, 1Kohm to each input (resistors built-in)
- Dry relays (external power supply)
- Dry relay max pass-through power: 24VDC @ 2A (resistive load); 2x auxiliary dry relays
- Wet relays (powered by AC43)
- Wet relay switch-selectable power: 12V operation 700mA max; 24V operation 350mA max
- Power consumption
- 98W maximum
- AC power input
- 100-240VAC 50/60Hz 1.5A maximum
- AUX power
- 1x 12V @ 250mA
- Connectivity
- Ethernet: 10/100Mbps RJ-45 for network connection; USB 2.0
- Operating temperature
- 32°F - 122°F / 0°C - 50°C, 5–90% humidity
- Dimensions
- Height: 16.4in / 417.0mm; Width: 12.6in / 321.0mm; Depth: 4.6in / 116.3mm
- Weight
- 14.0lbs / 6.35kg
- Mounting options
- Mounting plate and four wood screws
- Included accessories
- Lock key and flat head screwdriver
- Compliance & safety
- FCC Part 15B, ICES-003, CE, UKCA, RCM, VCCI, UL 294, ULC 60839-11-1, UL 62368-1, CSA C22.2 No 62368-1, IEC 62368, FY2019 NDAA compliant
- Availability
- US, CAN, EU, UK, AUS, NZ, JP
- Warranty
- 10 years
