Verkada TK74 7" Touchscreen Intercom

Intercoms · TK74

Verkada TK74 7" Touchscreen Intercom

The Verkada TK74 is a premium 7-inch touchscreen intercom that combines visitor management, two-way video calling and built-in access control in a single weatherproof unit.

Reviews & comments · Join the conversation
From$3,999HARDWARE

Required license priced separately. Choose your configuration below.

Get a volume quote
Overview

The Verkada TK74 is a premium 7-inch touchscreen intercom that combines visitor management, two-way video calling and built-in access control in a single weatherproof unit. The display wakes as someone approaches and adapts to ambient light, and it can be branded with your own logo, wallpaper and welcome message.

  • 7-inch vertically-oriented LCD touchscreen with on-screen tenant directory — visitors search by name, unit or department number, or scan an entry QR code
  • Sub-second Face Unlock for provisioned users, with 3D + IR depth sensing and liveness detection to block photo and video spoofing; up to 25,000 enrolled faces
  • 5MP camera (2592 x 1944) with a 130° horizontal field of view and 50ft / 15m infrared night vision
  • Two-way full-duplex audio: 5W 90dB speaker, four omnidirectional MEMS microphones, 3m pickup range, beamforming and echo cancellation
  • Integrated credential reader — Verkada DESFire EV3, MiFare, HID Prox II and 35/37-bit Wiegand formats, plus Verkada Pass, Apple Wallet and Android NFC
  • Calls route to the Verkada Pass app, Desk Station, Command, or an existing phone system over SIP, VoIP, PSTN or Zoom Phone, with failover steps and schedule-based logic
  • Built for multi-tenant properties: searchable call transcripts, annotated call events and dashboard analytics across every intercom and site
  • IP66 weatherproof and IK08 impact-rated, aluminium/steel/polycarbonate construction, 512GB onboard storage, 5-year warranty

Surface mount plate and rain hood are included. Requires an intercom device license; optional tenant licensing is sold separately per site in packs of 10 tenants.

Technical detail

Product specifications

Download datasheet (PDF)
Display
7-inch vertically-oriented LCD touchscreen, auto-wake on approach
Camera
5MP (2592 x 1944), 1/2.8" progressive CMOS, F2.0 fixed lens, 2.12mm
Field of view
130° horizontal / 100° vertical / 160° diagonal
IR range
50ft / 15m
Face Unlock
3D + IR liveness detection; 0.3–1.5m range; up to 25,000 faces
Audio
Two-way full duplex; 5W speaker at 90dB SPL (1m); 4x MEMS microphones
Credentials
Verkada DESFire EV3, MiFare/DESFire NFC, HID Prox II 26-bit, 35/37-bit Wiegand, Verkada Pass, Apple Wallet, Android NFC
Receivers
Verkada Pass app, Desk Station, Command; SIP, VoIP, PSTN, Zoom Phone
Onboard storage
512GB
Inputs / outputs
3x dry inputs, 2x dry relays (30VDC @ 1A), 1x RS-485 port
Power
PoE+ (IEEE 802.3at) 25.5W, or PoE++ (802.3bt) 40W
Operating temperature
PoE+: -4°F–122°F / -20°C–50°C; PoE++: -40°F–122°F / -40°C–50°C
Rating
IP66 weatherproof, IK08 impact resistant
Construction
Aluminum, steel, polycarbonate, glass
Dimensions / weight
5.1lb / 2.3kg
Included accessories
Surface mount plate, rain hood, T10 screwdriver, mounting hardware kit, grommet punch
Warranty
5 years
